Features
-
Very high output to size ratio—135.4 dB SPL (1 m) peak at only 15" tall
-
Tight musical "punch" combined with low-frequency extension down to 32 Hz
-
Extremely low profile (15") and small foot print
-
Screw-in (M20) pole mount for use with full-range pole mountable speakers
-
Elegant transport and handling features including an optional transport dolly plus soft cover and four thoughtfully placed handles
-
Premium-grade, long-excursion, high-power woofers with 4" voice coils
-
15 mm Birch ply enclosure with extensive internal bracing for rigidity and solid, accurate reproduction
-
Finish available in black.
SPECIFICATIONS
GP212-sw
Configuration
2 × 12-inch - 4th order band-pass subwoofer
Transducers
2 × 550 W, 8 ohm 12-inch woofer with a 4-inch voice coil, ceramic magnet assembly
Frequency Response (±3 dB)
40 Hz - 100 Hz (without processing)
Frequency Range (-10 dB)
32 Hz - 107 Hz (without processing)
Nominal Impedance
4 ohms
Continuous Power Capacity
1100 W
Recommended Power
1650–2200 W
Sensitivity (1 W at 1 m)
99 dB
Maximum Output—Continuous / Peak (SPL at 1 m)
129.4 dB / 135.4 dB
Cabinet Type
4th-order bandpass
Enclosure Material
15mm Baltic birch plywood
Finish
Available in Black
Connectors
2 × NL4 in parallel
Pinout
Pins
1+/1-Sub
2+/2-NC
Attachment Points
Six threaded M10 inserts
Dimensions (HWD)
381 × 508 × 737 mm
15 × 20 × 29 in
Carton Dimensions (HWD)
640 × 510 × 813 mm
25.2 × 20 × 32 in
Net Speaker Weight
45.1 kg / 99.5 lb
Shipping Weight
52.3 kg / 115.3 lb
Accessories Available (optional)
CP212-0 – Wood cart
All specifications are subject to change without notice.
